Hub 2 Plus Jeweller
Hub 2 Plus Jeweller
Security system control panel
Reliable communication with external entities is vital for alarm control panels, ensuring the swift transmission of alarm signals to the Alarm Receiving Center and system users.
Constant connectivity is ensured through cables, Wi-Fi, and LTE.
The Hub 2 Plus enhances this reliability by offering four communication channels, including LTE support. This setup enables connections to two distinct Internet providers via Ethernet and Wi-Fi, with two cellular networks on standby for backup. Channel switching is executed seamlessly, ensuring continuous communication without interruption.
Range Expand capabilities
Integrating devices with ReX 2 secures and automates large-scale facilities such as business centers, estates, warehouse complexes, or production sites. Within the Ajax system, up to five range extenders can be utilized, extending radio network coverage to 35 km². Events and alarms are relayed immediately, with the initial photo verification snapshot reaching monitoring stations and users within 10 seconds.
Securing large premises with intricate internal structures
Hub 2 Plus is equipped to safeguard complex properties such as business centers, factories, and multi-story villas with outbuildings. This advanced hub can manage up to 200 devices, with a radio signal range extending up to 2,000 meters and a maximum radio network coverage of 35 km². It supports 25 security groups and accommodates a total of 200 users, enabling security teams to segment large areas into zones for streamlined access management.
Control your entire home from your phone
Our decision to forgo buttons on our control panel in favor of modern applications enhances both comfort and security. These apps establish a secure connection to a hub via Ajax Cloud—our server solution hosted across multiple AWS data centers. They empower users to manage security, adjust hub settings, configure connected devices, devise scenarios, and oversee events, all accessible from a smartphone or PC, whether on-site or remotely.
Control Everything in Сlassic Style
KeyPad TouchScreen Jeweller
All your devices in one place. A stylish keypad that will suit any interior. Allows you to control the entire security system via Bluetooth technology without using your phone. Good old control panels with new technologies.
All your devices in one place. A stylish keypad that will suit any interior. Allows you to control the entire security system via Bluetooth technology without using your phone. Good old control panels with new technologies.
Technical information
- Electro-optical combined radio channel security detector
- Wireless
Indoors
- Operates with all Ajax hubs, range extenders, ocBridge Plus, uartBridge
- PIR sensor, electret microphone
0.15 s
Up to 12 m
Horizontal — 88.5°
Vertical — 80°
Vertical — 80°
From 0.3 to 2 m/s
2.4 m
Weight — up to 20 kg
Height — up to 50 cm
Height — up to 50 cm
Communication range with central unit — up to 1,200 m in an open space
Two-way communication between devices
Radio frequency bands:
866.0 – 866.5 MHz
868.0 – 868.6 MHz
868.7 – 869.2 MHz
905.0 – 926.5 MHz
915.85 – 926.5 MHz
921.0 – 922.0 MHz
(depends on the region of sale)
Self-adjusting RF output power — up to 20 mW
Block encryption based on AES algorithm
Detector polling period — 12−300 s
Learn more about Jeweller
Two-way communication between devices
Radio frequency bands:
866.0 – 866.5 MHz
868.0 – 868.6 MHz
868.7 – 869.2 MHz
905.0 – 926.5 MHz
915.85 – 926.5 MHz
921.0 – 922.0 MHz
(depends on the region of sale)
Self-adjusting RF output power — up to 20 mW
Block encryption based on AES algorithm
Detector polling period — 12−300 s
Learn more about Jeweller
CombiProtect combined motion and glass break detector
SmartBracket mounting panel
CR123A battery (pre-installed)
Installation set
User's guide
SmartBracket mounting panel
CR123A battery (pre-installed)
Installation set
User's guide
Replacement and repair within 24 months of the date of sale. Batteries are not covered under warranty.
